Product Details:
Payment & Shipping Terms:
|
Alloy Grade: | 1050 1100 | Product Name: | Polyester Aluminum Coils |
---|---|---|---|
Size: | 0.02mm- 1.2mm Or Custom Made | Surface: | Polyester Coating |
Application: | Roofing, Ceiling, Wall Construction, Insulation Panel | Color: | Solid, Metallic, High Gloss, Stone,Timber, Brush, Mirror, Sparking |
High Light: | aluminum roofing coil,painted aluminium coil |
PVDF PE(Polyester) glossy epoxy polyamide polyurethane aluminum coating coils 1100 1050
The production process of continuous coil coating starts with a chemical treatment of the input strip, which removes anticorrosive oils and dust impurities by multistep rinsing. A non-chromatic passive layer, securing a good adhesion of the coating, is applied to the cleaned surface. After the passive layer dries, a system of cylinders applies polyester, polyurethane or PVDF coatings to the strip. After the application of the coating, the strip is baked in ovens at a temperature of up to 240 °C
Color Match of PVDF Coated Coil
1. For custom' color requests, we can deal as following:
Supply a physical sample of custom color. A color sample on metal is preferred. If other, it is also acceptable. But the color matching rate may be not good as color on metal.
New color sample is usually offered by our paint supplier in 5-7 days, special color should be in 7-10 days.
Upon receipt of color sample, please approve in writing as soon as possible. Once you approved, we will arrange purchasing and production
Note:
Color difference maybe occurred in different production batch, so it is suggested all panels are placed in one order for same project. And keep same direction as arrow on protective film when installing to avoid any color difference by vision.
Classification of Coated Aluminum Coil
As per types of surface coating of paint, color coated aluminum coils can be divided into polyester (PE) coated aluminum coil, fluorocarbon (PVDF) coating aluminum coil and Epoxy coated aluminum coil.
PVDF Coated Aluminum Coil Quick Details
Alloy | 1100 3003 5005 1050 1060 1070 3102 8011 3A21 3105 8079 |
Aluminum thickness | 0.02mm-1.2mm |
Aluminum max Width | 2200mm standard width: 1240mm special width such as 1300mm, 1520mm, 1570mm,1595mm are also available |
Coil's standard diameter | interior diameter: 150mm, 405mm, 505mm |
Coating finish | PVDF, PLOYESTER, ACRYLIC ACID |
MOQ | 5 tons per size |
Gloss | meet the customer's requirement |
Total coating thickness | PVDF coating: more than 25 microns |
Coating adhesive | no lower than first grade |
Impact resistance | no cracking and peeling (50kg/cm, ASTMD-2794:1993) |
Outer packing | export standard, wooden pallet |
Xiaoxian RuiYi is a professional supplier cooperated with factory supplying quality aluminum materials like aluminium sheet, aluminum coils, coated aluminum coils, treadplates, diamond aluminum plate sheet, 5 bars aluminum sheet, stucco aluminum coils.
We can supply alloy as follows
Alloy: 1050 1060 1100 3003, 3105, 5052, 5005, 5754 5083 5182, 6061 6063 6082, 7075, 8011…
Temper: HO, H111,H12, H14, H24,H 32, H112, T4, T6, T5,T651
Surface:Mill/Emboss/Diamond/2bar/3bars/Bright
Thickness: 0.2mm to 300mm
Width: 30mm to 2300mm
Length:1000mm to 10000mm.
Awaiting for your new request with details.
Chemical Analysis of aluminum alloy Plate | ||||||||||
Alloy | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | Al |
1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | - | - | 0.05 | 0.03 | Remains |
1060 | 0.25 | 0.35 | 0.05 | 0.03 | - | - | - | - | - | Remains |
1070 | 0.2 | 0.25 | 0.04 | 0.03 | 0.03 | - | - | - | - | Remains |
1100 | 0.95 | 0.95 | 0.05-0.2 | 0.05 | - | - | 0.1 | - | - | Remains |
1200 | 1 | 1 | 0.05 | 0.05 | - | - | - | 0.1 | 0.05 | Remains |
3003 | 0.6 | 0.7 | 0.05-0.2 | 1.0-1.5 | - | - | - | 0.1 | - | Remains |
5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.5-1.1 | 0.1 | - | 0.25 | - | Remains |
5042 | 0.2 | 0.35 | 0.15 | 0.2--.5 | 3.0-4.0 | 0.1 | - | 0.25 | 0.1 | Remains |
5052 | 0.25 | 0.4 | 0.1 | 0.1 | 2.2-2.8 | 0.15-0.35 | - | 0.1 | - | Remains |
5083 | 0.4 | 0.4 | 0.1 | 0.4-1.0 | 4.0-4.9 | 0.05-0.25 | - | 0.25 | - | Remains |
5754 | 0.4 | 0.4 | 0.1 | 0.5 | 2.6-3.6 | 0.3 | - | 0.2 | - | Remains |
6061 | 0.4-0.8 | 0.7 | 0.15-0.4 | 0.15 | 0.8-1.2 | 0.04-0.35 | - | 0.25 | - | Remains |
6063 | 0.2-0.6 | 0.35 | 0.1 | 0.1 | 0.45 | 0.1 | - | 0.1 | - | Remains |
6082 | 0.7-1.3 | 0.5 | 0.1 | 0.4-1.0 | 0.6-1.2 | 0.25 | - | 0.2 | - | Remains |
7050 | 0.12 | 0.15 | 2.0-2.6 | 0.1 | 1.9-2.6 | 0.04 | - | 5.7-6.7 | 0.06 | Remains |
7075 | 0.4 | 0.5 | 1.2-2.0 | 0.3 | 2.1-2.9 | 0.18-0.28 | - | 5.1-6.1 | 0.2 | Remains |
